Multimeter MM-1
Regular price
£21.05
Regular price
Sale price
£21.05
Unit price
per
A highly reliable 3½ digit autoranging digital multimeter with data hold function. Ideal for general maintenance work.
Wide range of functions with 29 ranges including:
Select model
| Variant | Price (exc tax) | ||
|---|---|---|---|
|
MM-1
Multimeter with leads and probes, 1000VDC, 750VAC |
Regular price
£21.05
Regular price
Unit price
per
|
||
Multimeter MM-1
A highly reliable 3½ digit autoranging digital multimeter with data hold function. Ideal for general maintenance work.
Wide range of functions with 29 ranges including:
- Continuity buzzer
- Transistor test
- Capacitance test
- Diode test
Supplied complete with test leads, holster, battery and manual.
Size: 172x83x38mm
Weight: 310g approx.
RoHS compliant
| Basic Functions |
Range
|
Best Accuracy
|
| DC Voltage | 200mV/2V/20V/200V/1000V | ±(0.5%+1) |
| AC Voltage | 2V/20V/200V/750V | ±(0.8%+3) |
| DC Current | 20µA/200µA/2mA/20mA/200mA/10A | ±(0.8%+1) |
| AC Current | 200µA/20mA/200mA/10A | ±(1%+3) |
| Resistance | 200Ω/2kΩ/20KΩ/200KΩ/2MΩ/200MΩ | ±(0.8%+1) |
| Capacitance | 2µF | ±(4%+3) |
| Special Functions | ||
| Diode test | Yes | |
| Continuity Buzzer | Yes | |
| Transistor test | Yes | |
| Sleep Mode | Yes | |
| Low Battery Display | Yes | |
|
Input Impedance for DC Voltage Measurement |
10MΩ | |
| Max. Display | 1999 | |
| Display size: | 61x32mm | |
| Power | 9V Battery (PP3) |
Quick Links
Good to know
Technical Specifications
| SKU | MM-1 |
|---|---|
| Weight (kg) | 0.31 |
| Intrastat Commodity Code | 90303391 |
*see manufacturer's documentation for further information
