Mercedes-Benz Energy Storage Home

Bookmark and Share

Mercedes-Benz Energy Storage Home:
Quality with the star. Made in Germany.


The compact Mercedes-Benz Energy Storage Home features state-of-the-art lithium-ion batteries that have been perfected for use in demanding automotive applications. Up to eight battery modules with an individual capacity of 2.5 kWh can be combined to create an energy storage system with an overall capacity of 20 kWh.

The long service life is guaranteed by Mercedes-Benz quality – expected battery lifetime is rated at 8,000 cycles and residual capacity after ten years of use at 80 percent.

Using a complete solution comprising of Mercedes-Benz Energy Storage Home, battery inverter and intelligent control, you can maximize your solar consumption and make your energy more independent and more efficient.

  • Designed for use with SMA Sunny Island inverters.
  • Very safe and durable lithium-ion technology
  • Automotive platform – developed for demanding use in the car
  • Modular system design (2.5–20 kWh)
  • Lifetime: approx. 80% capacity remaining after ten years
  • Expected number of cycles: 8,000
  • Saves resources
  • Greater power supply independence
  • Ten-year fair-value replacement warranty

Suitable for either floor or wall mounting.

Up to four storage modules can be fitted with one cover and the appropriate base and mounting rails in one unit. Two such units can then be combined using an external combiner junction box to increase storage capacity up to 20kWh.

Mercedes-Benz Energy Storage Home Battery Modules Mercedes-Benz Energy Storage Home Battery Top

Mercedes-Benz System Cover

Silver cover with Mercedes-Benz star. One required for each set of up to four energy storage modules.

Mercedes-Benz Energy Storage Home Battery System Cover
Product Added! click here to view basket Failed! Could not add product to basket, please try again.
Product Code Description Retail Price
(ex VAT)
MBEH-TP-150 Cover (with Mecedes-Benz Star) £137.14

Mercedes-Benz Energy Storage Module

2.5kWh energy storage module using nickel/manganese/cobalt lithium-ion cell technology . Up to eight energy storage modules can be used to give a total capacity of 20kWh.

  • 2.3kWh useable capacity
  • 8,000 cycles lifetime (to 80% DOD)
  • 39.7 - 54 VDC operating range
  • 97% round cycle efficiency
Mercedes-Benz Energy Storage Home Battery Energy Storage Module
Product Added! click here to view basket Failed! Could not add product to basket, please try again.
Product Code Description Retail Price
(ex VAT)
MBEH-BA-150 Mercedes-Benz 2.5kWh energy storage module £1,099.69

Mercedes-Benz System Base (Floor-Standing)

Base suitable for floor mounting of the Mercedes-Benz energy storage modules. One required for up to four modules.

Mercedes-Benz System Base (Floor-Standing) Mercedes Benz Energy Storage Home Battery 5Kwh Floor Standing Front
Product Added! click here to view basket Failed! Could not add product to basket, please try again.
Product Code Description Retail Price
(ex VAT)
MBEH-FO-150 Base (floor standing) £232.88

Mercedes-Benz System Base (Wall-Mounted)

Base suitable for wall mounting of the Mercedes-Benz energy storage modules. One required for up to four modules.

Mercedes-Benz System Base (Wall-Mounted) Mercedes Benz Energy Storage Home Battery 5Kwh Wall Mounted Front
Product Added! click here to view basket Failed! Could not add product to basket, please try again.
Product Code Description Retail Price
(ex VAT)
MBEH-BO-150 Base (wall mounted) £116.44

Mercedes-Benz System Mounting Rails

The installation rails are required according to the number of energy storage modules and the installation type
(floor standing or wall-mounted).

The installation rails exactly match the number of energy storage modules . To extend a Mercedes-Benz Energy Storage system additional installation rails are required.

Mercedes-Benz Energy Storage Home Battery Installation Rails
Product Added! click here to view basket Failed! Could not add product to basket, please try again.
Product Code Description Retail Price
(ex VAT)
MBEH-S2-150 Mounting rails floor standing (2 modules) £18.11
MBEH-S3-150 Mounting rails floor standing (3 modules) £23.29
MBEH-S4-150 Mounting rails floor standing (4 modules) £25.88
MBEH-W2-150 Mounting rails wall mounted (2 modules) £18.11
MBEH-W3-150 Mounting rails wall mounted (3 modules) £23.29
MBEH-W4-150 Mounting rails wall mounted (4 modules) £25.88
