Victron Battery Protect
The Victron Battery Protect disconnects the battery from loads before the battery is completely discharged, this prevents damage to the battery and will leave some charge in the battery e.g. to start an engine.
Select model
| Variant | Price (exc VAT) | ||
|---|---|---|---|
|
VBP-65
Victron Battery Protect LV disconnect 12/24V 65A |
Regular price
£28.86
Regular price
Unit price
per
|
||
|
VBP-100
Victron Battery protect, LV disconnect 12/24V, 100A |
Regular price
£47.22
Regular price
Unit price
per
|
||
|
VBP-100/48
Victron Battery protect, LV disconnect 48V, 100A |
Regular price
£106.96
Regular price
Unit price
per
|
||
|
VBP-220
Victron Battery protect, LV disconnect 12/24V, 220A |
Regular price
£78.39
Regular price
Unit price
per
|
||
|
VBPS-65
Victron Smart battery protect 65A, 12/24V |
Regular price
£48.10
Regular price
Unit price
per
|
||
|
VBPS-100
Victron Smart battery protect 100A, 12/24V |
Regular price
£63.26
Regular price
Unit price
per
|
||
|
VBPS-100/48
Victron Smart battery protect, 100A, 48V |
Regular price
£122.05
Regular price
Unit price
per
|
||
|
VBPS-220
Victron Smart battery protect, 220A, 12/24V |
Regular price
£93.54
Regular price
Unit price
per
|
||
Victron Battery Protect
The Victron Battery Protect disconnects the battery from loads before the battery is completely discharged, this prevents damage to the battery and will leave some charge in the battery e.g. to start an engine.
It can also be used to with an external switch to remotely disconnect loads from the battery.
Highlights:
- 12V/24V models offer automatic system voltage detection
- Programmable without connection to computer (see manual for details)
- Over voltage protection, prevents damage to sensitive loads in case of over voltage
- Ignition proof, uses MOSFET switches so creates no sparks
- Delayed alarm output and load disconnect (see data sheet for details)
- 5 years warranty
Victron Smart Battery Protects include Bluetooth to allow any required engage/disengage levels to be set. Alternatively, one of nine predefined engage/disengage levels can be set with the programming pin (see manual). If required, Bluetooth can be disabled.
Good to know
Technical Specifications
| SKU | VBP-65 | VBP-100 | VBP-100/48 | VBP-220 | VBPS-65 | VBPS-100 | VBPS-100/48 | VBPS-220 |
|---|---|---|---|---|---|---|---|---|
| System Battery Voltage | 12V, 24V | 12V, 24V | 48V | 12V, 24V | 12V, 24V | 12V, 24V | 48V | 12V, 24V |
| Connection | M6 | M8 | M8 | M8 | M6 | M8 | M8 | M8 |
| Weight (kg) | 0.6 | 0.6 | 1.3 | 1 | 0.4 | 0.4 | 0.4 | 0.4 |
| Packaging Height | 130 | 190 | 70 | 150 | 130 | 190 | 70 | 150 |
| Packaging Width | 60 | 70 | 70 | 150 | 60 | 70 | 70 | 150 |
| Packaging Depth | 55 | 70 | 190 | 75 | 55 | 70 | 190 | 75 |
| Warranty | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Intrastat Commodity Code | 85364190 | 85364190 | 85364190 | 85364190 | 85364190 | 85364190 | 85364190 | 85364190 |
Downloads /
Documents
- Victron BatteryProtect 12 24V 65 100 220A Datasheet
- Victron BatteryProtect 48V 100A Datasheet 26bba2d3 fb9e 4dab 8465 e3d9de02e0b6
- Victron Smart BatteryProtect 12 24V 65 100 220A Datasheet a0594858 1362 45e1 b15c 20fd3c3a45d6
- Victron Smart BatteryProtect 48V 100A Datasheet 8de45c42 ca86 48f8 a8a6 e2d1b570f073
*see manufacturer's documentation for further information
