Victron SmartSolar Charge Controller MPPT 150/35 & 150/45

Victron Energy Logo
From £147.52
From £147.52
Sale Sold out
Shipping calculated at checkout.

This Victron SmartSolar Charge Controller supports a PV input with a maximum open circuit voltage of 150V and have a maximum output of up to 35A. They work with and will automatically recognise 12V, 24V and 48V battery systems (36V also possible via software configuration).

See full details

Retail customers
Many of the products we supply require training and experience to install, we recommend seeking the assistance of a professional to help you with your project.

Find the right installer for you

Trade customers
Please login or apply for a trade account for trade pricing, check stock and order online.

Log in / Apply for a trade account

Select model

Variant Price (exc VAT)
VSS-MPPT150/35
SmartSolar MPPT 35A ch.cont.150V input 12/24/48V out
£147.52
£147.52
VSS-MPPT150/45
SmartSolar MPPT 45A 150V input 12/24/36/48V out
£174.79
£174.79
(exc VAT)
Login for trade prices

Victron SmartSolar Charge Controller MPPT 150/35 & 150/45

This Victron SmartSolar Charge Controller supports a PV input with a maximum open circuit voltage of 150V and have a maximum output of up to 35A. They work with and will automatically recognise 12V, 24V and 48V battery systems (36V also possible via software configuration).

  • Internal BlueTooth for wireless communication with smartphones or tablets.
  • Ultra-fast Maximum Power Point Tracking (MPPT) for maximum energy harvest.
  • Advanced Maximum Power Point Detection in case of partial shading conditions
  • VE.Direct communication port
  • Up to 98% efficient
  • 8 preprogrammed algorithms selectable with a rotary switch
  • Electronic protection:
    • Battery reverse polarity (fuse, not user accessible)
    • PV reverse polarity / Output short circuit / Over temperature
  • Internal temperature sensor, compensates absorption and float charge voltages
  • 16 mm² screw terminals
  • 5 years warranty

Quick Links

Technical Specifications

Downloads

Good to know

Technical Specifications

SKUVSS-MPPT150/35VSS-MPPT150/45
System Battery Voltage 12V, 24V, 36V, 48V 12V, 24V, 36V, 48V
Max VOC 150V 150V
MPPT Trackers 1 1
Connectivity Bluetooth, VE.Direct Bluetooth, VE.Direct
Connection Screw terminals Screw terminals
Height 130 130
Width 186 186
Depth 70 70
Weight (kg) 1.25 1.25
Packaging Height 2035 205
Packaging Width 130 130
Packaging Depth 90 90
Warranty 5 5
IP Rating IP43 (electronic components), IP22 (connection area) IP43 (electronic components), IP22 (connection area)
On Grid / Off Grid Off Grid Off Grid
Lithium Compatibility Yes* Yes*
Intrastat Commodity Code 85044055 85044055

Downloads / Documents

*see manufacturer's documentation for further information
